PRO SQUID | Live underwater video system | GoPro video to TVs/plotters

from 1,450.00

The world’s first purpose-built housing for live streaming underwater footage from your GoPro is here.

The Spot X Pro Squid enables a live underwater feed from your GoPro to your plotter/TV/laptop/monitor, as well as supplying external power to the camera, eliminating the need for spare batteries.

*Listed price includes GST for Australian customers

**Registered companies, universities and government departments may place their order by supplying an official purchase order. Contact us for details

Cable Length (Metres):
Quantity:
Add To Cart

The Squid Underwater Drop Camera System

By accommodating GoPro HD cameras in our patented underwater housing, the Squid offers you the convenience of live streaming video, with the utility of full UHD 4K, presentation-ready footage. The ability to supply external power to your camera (via topside 12v power source) allows you to extend the runtime of your camera without requiring battery changes.

Pro Squid has the following features:

  • Crystal clear, zero latency SD* live feed, with up to 4k video recorded to camera memory card;

  • View on any TV/monitor or plotter which accepts a composite video feed (Squid cable has a male RCA connector, compatible display devices have a port typically marked as "AV In" or similar);

  • Compatible with GoPro Hero 3/3+ and 4 cameras. Support for Hero 5/6/7 cameras coming soon! Email us to stay updated.

  • Topside cable is terminated with a 5.5x2.1mm barrel connector, and supplied with a “cigarette lighter” style power cable for connection to a topside 12v power source (not included);

  • Dual viewing modes allows the Squid to be used facing forwards as a drop camera, or rear facing as a high speed tow camera;

  • Kevlar cable grip simplifies camera handling and protects cable;

  • Note, settings changes/start/stop camera etc is done on the surface using the GoPro app or WiFi remote control

Specifications

  • Camera compatibility- GoPro Hero 3/3+/4

  • *Zero latency (no lag) composite (appx 500TVL) video feed

  • Rated depth- 100 m

  • Video cable- Custom coaxial video cable, engineered for reliability, strengthened with kevlar fibre, with a water blocking gel to prevent damage and water ingress

  • Construction- Injection moulded from strong, UV stabilised plastics

Included with each Pro Squid:

- Housing & Lens

- Stabiliser Wing and Tail Fin

- Keel Weight

- Hard Case for Accessories

-NOTE, camera is not included

You can see some video examples of the Squid in use on our Gallery page.


The camera is great, it’s a really sturdy piece of kit and has even survived several run ins with the odd rock. Great communication and service from you guys too, I really appreciated that you sorted out the delivery to a small island on the other side of the world, thoroughly impressed.
— Samantha Blampied, PhD candidate, University of Plymouth

underwater video system demonstration

Book a free online demo

Real-time, personalised, no obligation demo streamed live from our test tank


Need more features?

Check out our ATC system



  • If you have any queries or requests, we're here to help. Please send us an email and we will get back to you promptly.

  • Registered companies and government organisations, simply email through your purchase order to be invoiced on delivery.
